Crust Bikes - Evasion Trail

The Evasion Trail 140 is a product of Matt's affinity for the mighty Postie Bike aka the Honda Trail 90 (or 110). In short, the Evasion Trail is exactly what it looks like, an Evasion rear end welded to a longer step thru front end, making it more compatible with a flat, riser, alt, townie, or whatever-you-call-it kind of bar. A non-drop bar kinda bike. The only major difference in standards is the Evasion Trail has Boost axle spacing in the rear AND the front. Matt did a whole write up about it on Dropped Chain. Check it, as well as a YouTube video about his sample Trail 140

HEADSET NOT INCLUDED

Details:

Handmade in Taiwan using Heat Treated Chromoly

Tig Welded

Color- Yellow

Sizes- Small 59cm | Medium 62cm | Large 65cm

Head Tube Diameter- 1 1/8" (Threadless Steerer)

Bottom Bracket- 73mm English (BSA) Threaded

Steerer Tube Length- 400mm

Axel to crown-385mm

Fork Spacing- 15x110mm

Rear End Spacing- 12x148mm

Front Axle Thread Pitch & Length- 1.5x135mm

Rear Axle Thread Pitch & Length- 1.5x173mm

Seat Post Diameter- 27.2mm

Seat Post Clamp Diameter- 30.0mm

Weight (Large)- Frame- 3kg or 6lbs 10oz | Fork (Uncut Steerer)- 1.53kg or 3lbs 6oz
