Stridsland - Beachcomber (crackle)

*ปรึกษาสอบถาม-สั่งประกอบ-สั่งเฟรมได้ครับ Line : https://lin.ee/PW6o6sU *

Description

The Beachcomber is my dream 26+ modern retro MTB; essentially the frame that matches the Barnacle fork. An All Terrain Bike if you must. Or as I like to call it, an MTBMX, as it’s basically an effort to merge a BMX and MTB into something functional. Its geometry is scientifically proven to enhance fun and adventure with the use of short-rear-end technology, an accommodatingly spacious front triangle, and yuge tire clearance (26 x 2.8″). It also sports an abundance of cage mounts, adjustable dropouts, and stealth dropper routing, utilizing only the most standardized standards such as a straight 1-1/8″ head tube, BSA threaded bottom bracket, IS disc brake mounts and external cable routing.

If you’d like a look at how the Beachcomber came to life, unpack the influences, riding philosophy and design decisions behind this playful, old-school-inspired, modern 26″ bike, click the link below.

Specs

– 12×142 rear spacing (non-boost)
– Rocker bolts recommended torque: 25-30Nm
– 15×100 front spacing (non-boost)
– 73mm bb shell BSA thread
– Max 38t chainring at 49mm chainline
– 1-1/8″ headtube for EC34 headsets
– 27.2mm seatpost post and 30.0mm seatclamp (steel frame)
– IS disc mounts front and rear
– Recommend 180 rotors but compatible with 160-203mm
– 4130 cro-mo, double butted front triangle, stainless steel dropouts
– Stainless M5 and M8 hardware
– Includes a Barnacle Lite fork + front and rear axles.
– Aprox 4,5kg – Large frame, fork (full length 300mm steerer), inserts, axles, hardware
– Headset not included

Wheel / Tire size

26 x 2.8″ – The essence of the Beachcomber lies within its 26+ platform. The geometry and clearances are optimized for this combination, as well as the way it’s intended to ride.

Also works great with 26 x 2.3″ tires, or up to 27.5 x 2.5″ at maximum.
